Epson EB-S04 User Manual

108
Projector Setup Settings - Extended Menu
Setting Options Description
When you set User's Logo Protection to On in the Password
Protection screen, you cannot change settings related to user's logo
a
Operation Direct Power On Selects various operation options:
display (Display Background, Startup Screen, A/V Mute in the
High Altitude Direct Power On: lets you turn on the
Display setting). Set User's Logo Protection to Off first.
Mode projector by plugging it in without
pressing the power button.
Auto Source Search
gg Related Links
High Altitude Mode: regulates the
Auto Power On
projector’s operating temperature at
• "Selecting Password Security Types" p.77
altitudes above 1500 m.
Auto Source Search: set to On to detect
the input signal automatically and
project images when there is no input
signal.
Auto Power On: select the image source
from which you want to automatically
start projection. When the projector
detects the input signal from the selected
image source, it projects automatically in
standby mode. To enable this feature,
connect the projector using a VGA
computer cable or USB cable.
USB Type B USB Display USB Display: enables the USB Display.
Link 21L Link 21L: enables ESC/VP21 commands.
Projector ID Off Assigns an ID for the projector when you
use multiple projectors.
1 through 9
Language Various languages Select the language for projector menu
available and message displays.
Reset — Resets all adjustment values on the
Extended menu to their default settings,
except for the following:
• User's Logo
• Projection
• High Altitude Mode
• Auto Source Search
• USB Type B
• Projector ID
• Language

Epson EB-S04 Specifications

General

Native aspect ratio	-
Projection distance	1.77 - 2.4 m
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Projection distance (wide)	0.88 - 10.44 m
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	- 30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	277 W
Power consumption (economy mode)	207 W
Ethernet LAN (RJ-45) ports	0
Cables included	AC, VGA
Remote control type	IR
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Pallet width	800 mm
Pallet height	1190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	360 mm
Package width	350 mm
Package height	160 mm
Package weight	3829 g
