Projector Feature Settings - Settings Menu
Options on the Settings menu let you customize various projector features.
Setting Options Description
Volume Varying levels Adjusts the volume of projector’s speaker
available system.
Setting values are saved for each source.
Lock Setting Control Panel Lock Controls projector button locking to
secure the projector:
Full Lock: locks all buttons.
Partial Lock: locks all buttons except the
power button.
Off: no buttons locked.
Pointer Shape Changes the shape of the remote control
pointer.
Pointer 1:
Pointer 2:
Pointer 3:
Remote Receiver Front/Rear Limits reception of remote control
Setting Options Description
signals by the selected receiver; Off turns
Front
Keystone H/V-Keystone Adjusts image shape to rectangular
off all receivers.
Rear
(horizontally and vertically).
Quick Corner
Off
H/V-Keystone: select to manually
correct horizontal and vertical sides, or
User Button Power Assigns a menu option to the [User]
turn Auto V-Keystone and H-Keystone
Consumption button on the remote control for one-
Adjuster on or off.
touch access.
Info
Quick Corner: select to correct image
Deinterlacing
shape and alignment using an on-screen
Test Pattern
display.
Resolution
Split Screen Screen Size Divides the viewing area horizontally and
Display the QR
displays two images side-by-side (press
Source
Code
[Esc] to cancel split screen display).
Swap Screens
Audio Source
Display the QR
Code
Zoom — Adjusts the size of the projected image.
(EB-S31/EB-
S04/EB-S130/EB-
S300)

Epson EB-S04 Specifications

General

Native aspect ratio	-
Projection distance	1.77 - 2.4 m
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Projection distance (wide)	0.88 - 10.44 m
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	- 30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	277 W
Power consumption (economy mode)	207 W
Ethernet LAN (RJ-45) ports	0
Cables included	AC, VGA
Remote control type	IR
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Pallet width	800 mm
Pallet height	1190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	360 mm
Package width	350 mm
Package height	160 mm
Package weight	3829 g
