Epson EB-S04 User Manual

73
Color Difference Correction when Projecting from Multiple Projectors
c
Select Projector ID and press [Enter].
When lining up multiple projectors to project images, you can correct the
d
Use the arrow buttons to select the identification number you want to
brightness and color tone of each projector's image so that the images match use for the projector. Then press [Enter].
closely.
You can set a unique projector ID for each projector to operate them
individually using a remote control, and then correct the brightness and color
for each projector.
• In some cases the brightness and color tone may not match
completely even after correction.
a
• If brightness and color tone differences become more noticeable over
time, repeat the adjustments.
gg Related Links
• "Setting the Projector ID" p.73
• "Selecting the Projector You want to Operate" p.73
• "Matching Multiple-Projector Display Quality" p.75
e
Press [Menu] or [Esc] to exit the menus.
Setting the Projector ID
Repeat these steps for all the other projectors you want to operate from one
If you want to control multiple projectors from a remote control, give each
remote control.
projector a unique ID.
Selecting the Projector You want to Operate
a
Press the [Menu] button on the control panel or remote control.
After setting the projector's ID, select the ID for the projector you want to
b
Select the Extended menu and press [Enter].
operate using the remote control.

Epson EB-S04 Specifications

General

Native aspect ratio	-
Projection distance	1.77 - 2.4 m
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Projection distance (wide)	0.88 - 10.44 m
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	- 30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	277 W
Power consumption (economy mode)	207 W
Ethernet LAN (RJ-45) ports	0
Cables included	AC, VGA
Remote control type	IR
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Pallet width	800 mm
Pallet height	1190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	360 mm
Package width	350 mm
Package height	160 mm
Package weight	3829 g
