115
Projector Setup Settings - ECO Menu
Settings on the ECO menu let you customize projector functions to save
Setting Options Description
power.
Sleep Mode On Automatically turns off the projector
after an interval of inactivity (when On).
When you select a power-saving setting, a leaf icon appears next to the menu
Off
item.
Sleep Mode Timer 1 to 30 minutes Sets the interval for Sleep Mode.
Lens Cover Timer On Automatically turns off the projector
after 30 minutes if the lens cover is
Off
closed (when On).
A/V Mute Timer On Automatically turns off the projector
after 30 minutes if A/V Mute is enabled
Off
(when On).
Standby Mode Communication Communication On indicates that the
On projector can be monitored over a
network when the projector is in standby
Communication
mode. Enable this setting to allow the
Off
following operations to occur when the
projector is in standby mode:
Monitor and control the projector over
a network
ECO Display On Displays a leaf icon in the bottom left
corner of the projected screen to indicate
Off
Setting Options Description
the power-saving status when the lamp
brightness changes (when On).
Power Normal Selects the brightness mode of the
Consumption projector lamp:
ECO
Reset Resets all adjustment values on the ECO
Normal: sets maximum lamp brightness.
menu to their default settings, except for
Standby Mode.
ECO: reduces lamp brightness and fan
noise, and saves power and lamp life.
You cannot select settings when you use
your projector at high altitude or in
When the Sleep Mode Timer setting is enabled, the lamp dims for a
locations subject to high temperatures.
short time before the timer limit is reached and the projector turns
a
off.
Light Optimizer On When set to On, the lamp brightness is
When the Lens Cover Timer or A/V Mute Timer settings are
adjusted according to the projected
(Available when Off
enabled, the lamp uses less power when the lens cover is closed or
image. This helps to reduce the power
Power
A/V Mute is activated.
consumption by lowering the lamp
Consumption is set
brightness according to the scene being
to Normal.)
projected.
gg Related Links
The setting is stored for each Color
"Projector Setup Settings - Extended Menu" p.107
Mode.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-S04 and is the answer not in the manual?

Epson EB-S04 Specifications

General IconGeneral
Native aspect ratio-
Projection distance1.77 - 2.4 m
Projection technology3LCD
Contrast ratio (typical)15000:1
Projection distance (wide)0.88 - 10.44 m
Projector native resolutionSVGA (800x600)
Keystone correction, vertical-30 - 30 °
Keystone correction, horizontal- 30 - 30 °
Projector brightness (economic mode)2100 ANSI lumens
FocusManual
Throw ratio1.45 - 1.96:1
Digital zoom1.35 x
Lamp typeUHE
Lamp power200 W
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
RMS rated power1 W
Number of built-in speakers1
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorWhite
Built-in displayNo
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.26 W
Power consumption (typical)277 W
Power consumption (economy mode)207 W
Ethernet LAN (RJ-45) ports0
Cables includedAC, VGA
Remote control typeIR
Operating altitude0 - 3000 m
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Noise level37 dB
Country of originPhilippines
Noise level (economic mode)28 dB
USB connector typeUSB Type-A, USB Type-B
HDMI connector typeFull-size
USB 2.0 ports quantity2
Pallet width800 mm
Pallet height1190 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth234 mm
Width297 mm
Height77 mm
Weight2400 g
Package depth360 mm
Package width350 mm
Package height160 mm
Package weight3829 g
