Epson EB-S04 User Manual

142
Solving Image or Sound Problems
• "Projector Setup Settings - ECO Menu" p.115
Solutions When the Image Brightness or Colors are Solutions to Sound Problems
Incorrect
If there is no sound or the volume is too low or high, try the following
solutions:
If the projected image is too dark or light, or the colors are incorrect, try the
following solutions:
• Adjust the projector's volume settings.
• Press the [Color Mode] button on the remote control to try different color • Press the [A/V Mute] button on the remote control to resume video and
modes for the image and environment. audio if they were temporarily stopped.
• Check your video source settings. • Check your computer or video source to make sure the volume is turned up
and the audio output is set for the correct source.
• Adjust the available settings on the projector's Image menu for the current
input source, such as Brightness, Contrast, Tint, Color Temp., and/or • Disconnect the audio cable, and then reconnect it.
Color Saturation.
• Check the audio cable connections between the projector and your video
• Make sure you selected the correct Input Signal or Video Signal setting in source.
the projector's Signal menu, if available for your image source.
• If you do not hear sound from an HDMI source, set the connected device to
s Signal > Advanced > Input Signal
PCM output.
s Signal > Advanced > Video Signal
• Make sure any connected audio cables are labeled "No Resistance".
• Make sure all the cables are securely connected to the projector and your
• If you are using the USB Display function, turn on the Output audio from
video device. If you connected long cables, try connecting shorter cables.
the projector setting in the Epson USB Display Settings program on your
• If you are using the ECO as the Power Consumption setting, try selecting
computer.
Normal in the projector's ECO menu.
• When you are connecting the projector to a Mac using an HDMI cable,
make sure your Mac supports audio through the HDMI port.
At high altitudes or locations subject to high temperatures, the image
• If the volume for the computer is set to the minimum while the projector is
may become darker and you may not be able to adjust the Power
a
set to the maximum, the noise may be mixed. Turn up the computer's
Consumption setting.
volume and turn down the projector's volume. (When you use EasyMP
Network Projection, EasyMP Multi PC Projection, USB Display or Quick
• Position the projector close enough to the screen.
Wireless Connection.)
• If the image has been progressively darkening, you may need to replace the
projector lamp soon.
gg Related Links
• "Projector Connections" p.21
gg Related Links
• "Projector Setup Settings - Extended Menu" p.107
• "Color Mode" p.53
• "Projector Setup Settings - ECO Menu" p.115
• "Input Signal Settings - Signal Menu" p.103
• "Controlling the Volume with the Volume Buttons" p.55
• "Image Quality Settings - Image Menu" p.101

Epson EB-S04 Specifications

General

Native aspect ratio	-
Projection distance	1.77 - 2.4 m
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Projection distance (wide)	0.88 - 10.44 m
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	- 30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	277 W
Power consumption (economy mode)	207 W
Ethernet LAN (RJ-45) ports	0
Cables included	AC, VGA
Remote control type	IR
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Pallet width	800 mm
Pallet height	1190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	360 mm
Package width	350 mm
Package height	160 mm
Package weight	3829 g
