Epson EB-S04 User Manual

51
Image Aspect Ratio
The projector can display images in different width-to-height ratios called
To display images without black bars, set Resolution to Wide or
aspect ratios. Normally, the input signal from your video source determines
Normal in the projector’s Signal menu according to the computer’s
a
the image's aspect ratio. However, for certain images you can change the
resolution.
aspect ratio to fit your screen by pressing a button on the remote control.
If you always want to use a particular aspect ratio for a certain video input
gg Related Links
source, you can select it using the projector's Signal menu.
• "Input Signal Settings - Signal Menu" p.103
gg Related Links
• "Changing the Image Aspect Ratio" p.51
Available Image Aspect Ratios
• "Available Image Aspect Ratios" p.51
• "Projected Image Appearance with Each Aspect Mode" p.52
You can select the following image aspect ratios, depending on the input
• "Input Signal Settings - Signal Menu" p.103
signal from your image source.
Changing the Image Aspect Ratio
• Black bands and cropped images may project in certain aspect ratios,
depending on the aspect ratio and resolution of your input signal.
a
You can change the aspect ratio of the displayed image.
• The Auto aspect ratio setting is available only for HDMI/MHL image
sources.
a
Turn on the projector and switch to the image source you want to use.
For projectors with a resolution of WUXGA (1920 × 1200) or WXGA
b
Press the [Aspect] button on the remote control.
(1280 × 800)
Aspect mode Description
Auto Automatically sets the aspect ratio according to the
input signal and the Resolution setting.
Normal Displays images using the full projection area and
maintains the aspect ratio of the image.
16:9 Converts the aspect ratio of the image to 16:9.
Full Displays images using the full size of the projection
area, but does not maintain the aspect ratio.
Zoom Displays images using the full width of the projection
c
To cycle through the available aspect ratios for your input signal, press
area and maintains the aspect ratio of the image.
the [Aspect] button repeatedly.
Native Displays images as is (aspect ratio and resolution are
maintained).

Epson EB-S04 Specifications

General

Native aspect ratio	-
Projection distance	1.77 - 2.4 m
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Projection distance (wide)	0.88 - 10.44 m
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	- 30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	277 W
Power consumption (economy mode)	207 W
Ethernet LAN (RJ-45) ports	0
Cables included	AC, VGA
Remote control type	IR
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Pallet width	800 mm
Pallet height	1190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	360 mm
Package width	350 mm
Package height	160 mm
Package weight	3829 g
