Epson EB-S04 User Manual

107
Projector Setup Settings - Extended Menu
Settings on the Extended menu let you customize various projector setup
Setting Options Description
features.
Display Messages Selects various display options:
Display Messages: set to On to display messages
Background such as input source name, color mode
name, aspect ratio, no signal message, or
Startup Screen
high temperature warning on your
A/V Mute
projected image.
Display Background: sets the screen
color or logo to display when no signal is
received.
Startup Screen: set to On to display the
user's logo when projection starts.
A/V Mute: sets the screen color or logo
to display when A/V Mute is turned on.
User's Logo — Creates a screen that the projector
displays to identify itself and enhance
security.
Projection Front Selects the way the projector faces the
screen so the image is oriented correctly.
Front/Ceiling
Setting Options Description
Rear
Home Screen Home Screen Auto Selects the projector's Home screen
Rear/Ceiling
Disp. display options:
Custom Function 1 Home Screen Auto Disp.: select whether
or not to display the Home screen
Custom Function 2
automatically.
Custom Function 1/Custom Function
2: select to set functions and the display
as the customized Home screen.

Epson EB-S04 Specifications

General

Native aspect ratio	-
Projection distance	1.77 - 2.4 m
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Projection distance (wide)	0.88 - 10.44 m
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	- 30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	277 W
Power consumption (economy mode)	207 W
Ethernet LAN (RJ-45) ports	0
Cables included	AC, VGA
Remote control type	IR
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Pallet width	800 mm
Pallet height	1190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	360 mm
Package width	350 mm
Package height	160 mm
Package weight	3829 g
