Projector Parts and Functions
Name Function Name Function
A
Turns the projector on or off.
P
[Home] button Displays and closes the Home screen.
Power button [ ]
From now on, referred to as the power button.
Q
[Freeze] button Pauses or resumes images.
B
[Computer] button Selects the Computer port as the image source.
R
[Volume] up/down Adjusts the speaker volume.
buttons
C
[Video] button Switches the image source between the S-Video, Video
and HDMI port.
S
[Pointer] button Displays the on-screen pointer.
D
Numeric buttons Enters numbers in the projector's menu while holding
T
[Esc] button Stops the current function.
down the [Num] button.
Moves back to the previous menu level while
E
[Auto] button Optimizes Tracking, Sync., and Position in the displaying the projector's menu.
projector's Signal menu while projecting an analog
Acts as a mouse's right button when using the Wireless
RGB signal from the Computer port.
Mouse function.
F
[Aspect] button Changes the aspect mode.
U
[ID] button Hold down this button and press the numeric buttons
to select the ID for the projector you want to operate
G
[Num] button Hold down this button to enter numbers using the
using the remote control.
numeric buttons.
V
[Color Mode] button Changes the color mode.
H
[Menu] button Displays and closes the projector's menu.
W
[MHL Menu] button Displays the settings menu for the device linked to the
I
Arrow buttons Selects menu items while displaying the projector's
projector's HDMI/MHL port.
menu or help.
X
[LAN] button Switches the image source between the network
J
[Enter] button [ ] Enters the current selection and moves to the next level
connected devices.
while displaying the projector's menu or help.
Acts as a mouse's left button when using the Wireless
Y
[USB] button Switches the image source between the USB Display
Mouse function. and USB-A port.
From now on, referred to as the [Enter] button.
Z
[Source Search] Changes to the next input source.
button
K
[User] button Performs settings assigned in the User Button setting
in the projector's Settings menu.
a
Remote control light Outputs remote control signals.
emitting area
L
[Page] up/down Controls page up and down on your computer when
buttons you connect a projector and computer using a USB
cable or over a network.
gg Related Links
Displays the previous or next screen while using the PC
• "Image Aspect Ratio" p.51
Free feature.
• "Color Mode" p.53
M
[E-Zoom +/–] Zooms in or zooms out the image area.
• "Input Signal Settings - Signal Menu" p.103
buttons
• "Projector Setup Settings - Extended Menu" p.107
N
[A/V Mute] button Turns the video and audio on or off temporarily.
• "Projecting Two Images Simultaneously" p.57
• "Using the Remote Control as a Wireless Mouse" p.68
O
[Split] button Projects two images from different image sources
simultaneously by splitting the projected screen.
• "Using the Remote Control as a Pointer" p.70
To Next Page
