FX-1880/880 Service Manual
Chapter 1 Product Description
Rev.B
1-
2
PAPER / MEDIA
Table 1-3. Cut Sheet
Insertion Front entry Rear entry
Width FX-1880:
FX-880:
148 ~ 420mm (5.8 ~ 16.5”)
148 ~ 257mm (5.8 ~ 10.1”)
Length 182 ~ 364mm ( 7.2 ~ 14.3 ) 92 ~ 364mm ( 3.6 ~ 14.3")
Thickness 0.065 ~ 0.14mm ( 0.0025~ 0.0055")
Weight 52 ~ 90g/m
2
(14 ~ 24 lb)
Quality Plain paper, Reclaimed paper , not curled, not folded, not crumpled
Table 1-4. Cut Sheet ( Multi-Part )
Insertion Front entry
Width FX-1880:
FX-880:
148 ~ 420mm (5.8 ~ 16.5”)
148 ~ 257mm (5.8 ~ 10.1”)
Length 182 ~ 364mm ( 7.2 ~ 14.3")
Copies 1(original) + 5
Total thickness 0.12 ~ 0.46mm ( 0.0047 ~ 0.018" )
Weight 40 ~ 58g/m
2
( 12 ~ 15 lb)
Quality Plain paper, Reclaimed paper, not curled, not folded, not crumpled
Jointing Line glue at the top or one side of a form
Table 1-5. Envelope
Insertion Rear entry only
Envelope <No.6> <No.10>
Width 165mm ( 6.5" ) 241mm ( 9.5" )
Length 92mm ( 3.6" ) 105mm ( 4.1")
Total thickness 0.16 ~ 0.52mm ( 0.0063 ~ 0.020" )
The difference of thickness at the printable area is within 0.25mm
( 0.0098" )
Weight 45 ~ 90g/m
2
( 12 ~ 24 lb )
Quality BOND paper, plain paper, AIR MAIL, no glue at a flap, not curled, not
folded, not crumpled
Table 1-6 Continuous Paper ( Single Sheet and Multi-Part )
Insertion Front entry, Rear entry, Bottom entry
Width FX-1880:
FX-880:
101.6 ~ 406.4mm ( 4 ~ 16” )
101.6 ~ 254mm ( 4 ~ 10” )
Length 101.6 ~ 558.8mm ( 4 ~ 22” )
Copies 1(original) + 5
Total thickness 0.065 ~0.46mm ( 0.0025 ~ 0.018” )
Weight 52 ~ 82g/m
2
( 14 ~ 22 lb )
Weight ( multi part) 40 ~ 58g/m
2
( 12 ~ 15 lb )
Quality Plain paper, Reclaimed paper, carbon less multi part paper
Jointing Point glue or both sides paper staple
