1.2.3 Indicators ( LEDs )
This printer has the following indicators to indicate its current condition, as shown in the table
below:
1.
Pause
( Orange )
• Comes On when the printer is paused, and goes Off when the printer is not paused.
• Blinks when the Micro adjust function and the Font selection are enabled or the printhead is
in the overheated condition.
2.
Paper Out
( Red )
• Comes On when the printer is in the Paper out condition.
• Blinks when the paper eject error has occurred .
3.
Tear Off / Bin
( Green )
• Blinks when the continuos paper is in the tear off position.
• Comes On when the CSF Bin1 is selected, and goes Off when the CSF Bin2 is selected.
4.
Font
( Green )
Indicates the font selections.
Table 1-10. LED Status
Printer status Font
Tear-Off /
Bin
Pause Paper Out
Pause
On
Paper out error
On On
Release lever error
On
Paper eject warning
On Blinks
Head hot warning
Blinks Blinks
Micro adjust & Font selection
Blinks
Tear off
According as
paper path
Bin selection
According as
bin selection
Font selection
According as
font selection
Fatal error Blinks Blinks Blinks Blinks
1.2.4 Buzzer
This printer has the buzzer to indicate its current condition with the following indications:
Table 1-11. Buzzer Status
Printer status Beep sounds
Paper out error
yyy
Release lever error – – – – –
Paper eject warning
yyy
Illegal panel operation
y
Note: The symbols used in the table represents the following:
“
y
” = A beep sounds for approximately 100 ms with the interval of approximately 100 ms.
“ – “ = A beep sounds for approximately 500ms with the interval of approximately 100ms.
