FX-1180/FX-880 Service Manual
Chapter 2 Operating Principles
Rev. B
2-
3
Tractor
Rear PE DEtector
CR Motor
Tim ing Belt
Carriage Unit
HP Detector
P rinthead
Platen R oller
P F M o to r
C R G uide S haft
PG Adjust Lever
R ibbon Feed M echanism
R elease Lever
Front P E detector
P a ra lle lis m B u s h in g
P a ra lle lis m B u s h in g
R elease D etector
Figure 2-3. Printer Mechanis Outline
