Epson LX-300+ User Manual

1
Setting Up the Printer 1-7
R4C4610
Rev. C
A5 size SETUP.FM
6/28/00 Pass 3
R
Proof Sign-off:
SEI Y.Ohkawara K.Kono
K.Kono
SEI M.Kauppi
Installing the ribbon cartridge
Before installing the ribbon cartridge, make sure the printer is not
plugged into an electrical outlet.
1. Open the printer cover to the upright position, then pull it up
to remove it.
w
Warning:
Never move the print head while the printer is turned on;
this can damage the printer. Also, if you have just used the
printer, let the print head cool for a few minutes before you
touch it.
2. Slide the print head to the middle of the printer.

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
