13. Overview of Functions and Registers

RX4111CE Jump to Top / Bottom
ETM62E-02 Seiko Epson Corporation 24
13.3.5. Power Switching Circuit-Related Register Bank3 02h
1) INIEN bit
This bit sets power switching operation and SPI-Bus communication stop at backup
2) SMPT1, SMPT0 bit
This bit sets the intermittent operation active time of the voltage monitoring circuit of the built-in MOS switch.
3) SWSEL1, SWSEL0 bit
When not using the power switching function, this bit sets the built-in MOS switch.
13.3.6. Time stamp-related register
Please refer to [13.8. Time stamp function] for the details.
1) Time stamp and status record register (Bank2 - 0h9h; Bank4, 5, 6, 7 - 0hFh)
This register records time stamp data from 1/1000 second digit to Year digit and internal state
when an event occurs.
2) Command trigger Time stamp control register (Bank2 - EhFh)
This register is used when triggering time stamp using SPI-Bus communication access.
3) Time stamp trigger control register (Bank3 - 5h)
This register is used to perform time stamp trigger.
13.3.7. RAM registers (Bank4, 5, 6, 7)
This RAM register is read/write accessible for any data in the range from 0h to Fh.
