14. How to use

RX4111CE Jump to Top / Bottom
ETM62E-02 Seiko Epson Corporation 49
2) TSCLR bit (Time Stamp Clear)
Initialization of Bank3 6h
Table 64 TSCLR bit
TSCLR
Data
Description
Write
0
No operation
1
Initialize Bank3 6h.
TSEMP: 1, TSFUL: 0, TSAD2,1,0: (1,1,1)
EISEL bit (Enable Interrupt Select)
Enable/Disable control of interrupt is output when 8-time stamp data becomes full.
Table 65 EISEL bit (Event Interrupt Select)
EISEL
Data
Description
Write
0
Each event makes interrupt output respectively from /INT.
1
In case of 8-time stamp full recording, interrupt output from /INT.
Even SPI-Bus command trigger is executed, it makes no interrupt output.
1) TSFUL bit (Time Stamp Full)
8-time stamp data area full recording
Table 66 TSFUL bit
TSFUL
Data
Description
Read
0
Time stamp RAM area is not full.
1
8 times of time stamp recording area is fully recorded.
2) TSEMP bit (Time Stamp Empty)
No recording date in RAM.
Table 67 Time Stamp Empty bit
TSEMP
Data
Description
Read
0

1

TSAD2, TSAD1, TSAD0 bit (Time Stamp Address pointer)
T
Table 68 TSAD bit
TSAD2, 1, 0
TSAD2
TSAD1
TSAD0
Address pointer
Read
0
0
0
Bank4 0h - 7h
0
0
1
Bank4 
0
1
0
Bank5 
0
1
1
Bank5 
1
0
0
Bank6 
1
0
1
Bank6 
1
1
0
Bank7 
1
1
1
Bank7 , default
