Epson SC-F9200 series Service Manual

SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 102
SE Group Confidential (Related Staff Only)
6. Disconnect the FFC from the connector of the Panel Board.
7. Disengage the two hooks and separate the Panel Unit from the Panel Unit Assy.
Figure 3-17. Removing the Panel Unit
Figure 3-18. Disassembled Panel Unit
Connector
Panel Unit
FFC
Hooks
Panel Unit
