Page #35 background image
SC-F9200 Series Revision C
PRODUCT DESCRIPTION Control Panel 35
SE Group Confidential (Related Staff Only)
1.5.2 Serviceman Mode
The Serviceman Mode is intended to be used by a service person for servicing the printer.
HOW TO START & QUIT
1. Turn the printer on by pressing the [Menu], [Back], and [OK] buttons together.
2. Turn the printer off to quit the Serviceman Mode.
SERVICEMAN MODE MENU LIST
Menu
Explanation
Class 1 2 3
Mecha Adjustment
Rear AD Adjusts the AD value of the PE Sensor.
CR Un Cap Unlocks or re-locks the carriage and uncaps/re-caps the Print Head.
LCD RGB Check
Red
Checks the operation of the LCD.Green
Blue
Panel Check Checks the operation of the buttons and the LEDs.
Sensor Check
PE
Checks the operation of sensors.
ILS
Life CR
PG
PGtyp
Used only in manufacturing processes. Not used in service operations.
PG+
PG++
H to F Speed
400 CPS
500 CPS
F to H Speed
400 CPS
500 CPS
Page Size
Fan
Life Count
