SC-F9200 Series Revision C
ADJUSTMENT Boards Related Checks and Adjustments 347
SE Group Confidential (Related Staff Only)
4.14.6 Check result of transferring data from CSIC chip
to Main Board
REQUIRED TOOLS
New Ink pack and Chip unit that is attached New Ink pack
New Ink Tank
EXECUTION MODE
Serviceman Mode
PROCEDURE
1. Turn the printer ON in the Serviceman Mode.
Turn the power ON while pressing [Menu] + [Back] + [OK].
2. Start the Service Program and select Check result of transferring data from
CSIC chip to Main Board.
3. Click [Run].
4. Pop-up message will be displayed and check whether the restore was successful or
not for each color.
(For each color, when restore was successful, “OK“ will be displayed and when
restore was not successful, “NG“ will be displayed.)
If firmware has Charge & Reservation function, depending on the
situation of Reservation, there are 2 cases where you can restore the
panel status and where you cannot restore the panel status.
When the panel status can be restored.
All colors were Reserved before replacing Main Board.
When the panel status can be restored partially.
Some of the colors were Reserved before replacing Main Board
When the panel status can Not be restored.
All of the colors were Not Reserved before replacing Main Board.
The condition of running the restore process is to perform the
following procedures in order. (Check also Mainboad Replacement
in Figure 4-1.)
1. Remove old Chip unit and slider before replacing Main Board.
2. Main Board initial setting (automatically power off)
3. Install slider and chip unit which you removed befor replacing
Main Board
4. Lower the slider’s levers.
5. Turn the power On in normal mode.
If you perform the procedure correctly, restore process will be
failed. And restore process runs only 1 time.
(If you want to run restore process again, install the New Main
Boad again and perform the procedure correctly. If you don’t have
new Main Board, you need to perform the procedure from Step5.)
To Next Page
