Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
PRODUCT DESCRIPTION Hardware Specifications 19
SE Group Confidential (Related Staff Only)
SLIDER
Figure 1-6. Front Side
INSIDE
Figure 1-7. Inside
Table 1-12. Slider
No.
Name
1 Slider
2 Ink inlet cover
3 Chip unit
Table 1-13. Inside
No.
Name
1 Print head
2 Media holding plate
3 Cutter groove
4 Pressure rollers
5 Platen
6 Wiper cleaner
7 Anti-drying caps
8 Suction caps
9Wiper
