Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
PRODUCT DESCRIPTION Control Panel 26
SE Group Confidential (Related Staff Only)
Media Setup Customize Settings
1 to 30
(Media setting bank)
Heating & Drying Blank Area Feed
Mode 0 If there is a section without print data (a blank area) during a
job, the media is fed quickly. If the value for the selected mode
is small, the media is fed at a quicker speed. If this mode does
not allow the ink to dry sufficiently, see the following section
and change the mode.
Mode 1
Mode 2
Mode 3
Media Suction 0 to 10 Set it to a suction level appropriate for the used media.
Head Movement
Data Width
Choose the range in which the print head moves during printing.
[Data Width] restricts print head movement to the printed area.
Restricting the extent of print head movement increases print
speed.
If [Data Width] is selected, the print head will move the full
width of the largest media supported by the printer. Select this
option for more even print results with less variation.
Printer Full Width
Multi-Strike Printing
OFF Choose the number of times each line is printed.
2 to 8
Roll Type
Printable Side Out
Choose [Printable Side Out] or [Printable Side In] according to
how the media is rolled.
Printable Side In
Tension
Measurement
Periodically
Choose [Periodically] or [Every page] to have the printer
automatically monitor and adjust media tension during printing
for optimal results, [Off] to disable automatic tension
adjustment. [Periodically] is recommended in most
circumstances.
Select [Every page] for more precise tensioning, but note that
print times will increase.
Every Page
Table 1-17. Setup Menu
Menu Menu Item/Setting Values (shaded one is the default) Explanation
