Epson SC-F9200 series

SC-F9200 Series Revision C
ADJUSTMENT Ink Supply Related Checks and Adjustments 336
SE Group Confidential (Related Staff Only)
13. If magenta ink is less than 70 mm from the bottom of the ink tank, fill the ink tank
with magenta ink.
14. Start the Service Program and select Push out Ink Charging (M+B).
15. Click [Run].
Figure 4-59. [Push out Ink Charging (M+B)] Screen
16. Select Nozzle Check on the Service Program, and print the nozzle check pattern.
17. Compare the nozzle check pattern with the one printed in Step2 and make sure
there is no nozzle clogging.
18. Turn off the printer.
C H E C K
P O I N T
It takes approximately 30 minutes to carry out Push out Ink
Charging (M+B). (Push out Ink Charging (M+B): 15 minutes,
Cleaning: 15 minutes)
C H E C K
P O I N T
Carry out Nozzle Check to check the color tone change before and
after switching over from normal black to HDK.
Printing a printer status sheet will make the check easier.
