Epson SC-F9200 series Service Manual

SC-F9200 Series Revision B
MAINTENANCE Exchange Parts 374
SE Group Confidential (Related Staff Only)
When exchanging any of the parts below, follow the flow chart below.
START
YES
YESYES
YES
NO
NONO
NO
Exchanging Print
Head?
Check Print Head life
(usage amount) by NVRAM
viewer. (See p.283)
Print Head usage
more than 80%?
Exchange all parts below.
- Print Head
- Ink Holder
- Duct CR
- Pump Cap Unit
- CR Motor
- Ink Tube
- Ink Tank
- PF Roller Center Support
Exchange the planned parts
only.
Check Print Head life
(usage amount) by NVRAM
viewer. (See p.283)
Print Head usage
more than 80%?
Check the lives (usage
amount) of other parts by
NVRAM viewer. (See p.283)
Any parts usage
more than 80%?
Exchange Print Head and
the parts with over 80%
usage.
Exchange Print Head only.
 Print Head
 Ink Holder
 Duct CR
 Pump Cap Unit
 CR Motor
 Ink Tube
 Ink Tank
 PF Roller Center Support
Exchange all parts below.
- Print Head
- Ink Holder
- Duct CR
- Pump Cap Unit
- CR Motor
- Ink Tube
- Ink Tank
- PF Roller Center Support
