SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 99
SE Group Confidential (Related Staff Only)
Figure 3-13. Unlocking the CR Unit
A
Insert driver (A)
CR locked
(The lever is raised)
- Right side -
Cover
CR Lock Lever
CR unlocked
(The Lever is lowered)
C A U T I O N
No clock rotation!
Insert driver (B)
