ADJUSTMENT Overview 207
Confidential
Paper feed
related parts/
units
Reel Motor
(for heavyweight roll
paper)
Replacement 1 p. 188
After
replacement
2 Turn the power on in Serviceman mode. ---

---
3 Reset the motor counter.

--- p. 229
Paper feed
related parts/
units
Roll (ATC) Motor
(for standard roll paper)
Replacement 1 p. 181
After
replacement
2 Turn the power on in Serviceman mode. ---

---
3 Reset the motor counter.

--- p. 229
Roll (ATC) Motor
(for heavyweight roll
paper)
Replacement 1 p. 181
After
replacement
2 Turn the power on in Serviceman mode. ---

---
3 Reset the motor counter.

--- p. 229
Heater related
parts/units
Heater
Replacement 1
p. 171/
p. 172/
p. 174
After
replacement
2 Turn the power on in Firmware update mode. ---

3 Heater function check

p. 270
Board related
parts/units
Main Board
(NVRAM backup OK)
Before
replacement
1 Turn the power on in Serviceman mode. ---

---
2 NV-RAM backup

--- p. 219
Replacement 3 p. 107
After
replacement
4 Turn the power on in Firmware update mode. ---

---
5 Update the firmware.

--- p. 227
6 Turn the power on in Serviceman mode. ---

---
7NV-RAM restore

--- p. 219
8 Turn the power on in normal mode. ---

---
9 Install ink cartridges ---

---
10 Reset the Main Board exchange counter.

--- p. 267
11 RTC & USB ID Input

--- p. 264
12
Verify that the date/time settings are correct on the control
panel.
---

---
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired
(Reattached) Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
