TROUBLE SHOOTING Remedies for Service Call Error 39
Confidential
122A
PF Motor
overload error
Overcurrent to the PF Motor was detected.
 PF Encoder cable is damaged.
 PF Motor cable is damaged.
 Irregular load
 PF Encoder failure
 PF Motor failure
Does the PF Encoder work properly? Check it using
the Service Program.
1. Replace the PF Encoder. (Page 162)
2. Replace the Main Board. (Page 107)
122D
PF Motor
driving time-out error
Abnormally-long driving duration of the PF Motor
was detected.
 Irregular load
 Firmware becomes out of control.
---
Replace the Main Board. (Page 107)
122E
PF Motor
velocity deviation error
The PF Motor was driven at a speed abnormally faster
than a predetermined one during acceleration or
deceleration.
 Irregular load
 PF Encoder failure
 PF Motor failure
 SUB Board is damaged.
 PF Motor driver failure
Does the PF Encoder work properly? Check it using
the Service Program.
1. Replace the PF Encoder. (Page 162)
2. Replace the PF Motor. (Page 161)
3. Replace the Main Board. (Page 107)
122F
PF Motor
lock error
The PF Motor was driven at a speed abnormally
slower than a predetermined one during operation.
 CR Encoder cable disconnection
 CR Motor cable disconnection
 Irregular load
 PF Encoder failure
 PF Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 PF Encoder to SUB Board (CN102)
 PF Motor to SUB-M Board (CN1)
2. Does the PF Encoder work properly? Check it
using the Service Program.
1. Replace the PF Encoder. (Page 162)
2. Replace the PF Motor. (Page 161)
131B
Head driver
(transmission gate)
overheat error
The temperature of the Head driver rises, and has
reached a predetermined limit.
1. Turn the power off and then back on. Does the
printer recover from the error?
2. Is the FFC connected to the connector properly
without being tilted?
1. Replace the Head FFC. (Page 123)
2. Replace the Print Head. (Page 121)
1418
Pump Motor
overcurrent error
 Connection failure of the Pump Motor or the Pump
Motor encoder.
 The number of occurrences of overcurrent to the
Pump Motor has reached a predetermined limit.
 Irregular load
 Pump Motor encoder failure
 Pump Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 Pump Motor (Pump Motor encoder) to Main
Board (CN210/CN203)
2. Does the Pump Motor encoder work properly?
Check it using the Service Program.
Replace the Pump Motor encoder and Pump Motor
(Pump Cap Unit). (Page 141)
Code Error Name Cause Check Item Remedy
