SC-S30600 Series Revision B
DISASSEMBLY & ASSEMBLY Parts Diagram 67
Confidential
Figure 3-3. Housing
R Maintenance Cover Sensor (p. 102)
Detects the Open/Closed status of the Right
Maintenance Cover.
Front Cover R Sensor (p. 104)
Detects the Open/Closed status of the Front Cover.
Front Cover L Sensor (p. 106)
Detects the Open/Closed status of the Front Cover.
L Maintenance Cover Sensor (p. 97)
Detects the Open/Closed status of the Left
Maintenance Cover.
