Epson Stylus Pro 7500 - Circuit Board Placement

EPSON Stylus Pro 7500 Revision A
Operating Principles Print Mechanism Components 71
CIRCUIT BOARD PLACEMENT
The panel unit is located i the right front of the printer and the AC inlet, power supply
circuit board and the C299MAIN circuit board are mounted in the compartment on the
printer’s rear side.
Figure 2-16. Circuit Board Layout
AC Inlet
Power Supply
Circuit Board
C299 MAIN
Circuit Board
