Epson SureColor SC-T3000 User Manual

Printable area
This section describes the printable areas for the printer.
If the margin set in an application is larger than the
following setting values, sections beyond the specified
margins are not printed. For example, if 15 mm is
selected for the left and right margins in the printer
menus and the document fills the page, the 15 mm at the
left and right sides of the page will not be printed.
Roll Paper Printable Area
The gray area in the illustration below shows the
printable area.
When printing borderless on the left and right, the left
and right margins are 0 mm. When printing borderless
on all edges, all margins are 0 mm.
The arrow in the illustration indicates the direction of
the ejected paper.
3~45mm
3mm/15mm
254mm~1118mm
254mm~914mm
254mm~620mm
127mm
~
15m
3mm/15mm 3mm/15mm
4
4
1
2
3
A
C
D
B
*1 SC-T7000 Series
*2 SC-T5000 Series
*3 SC-T3000 Series
*4 If Banner is selected for Roll Paper Option in the
printer driver Advanced tab, the top and bottom
margins are 0 mm.
Margins for roll paper depend on the option selected for
Roll Paper Margin in the menus, as shown in the table
below.
Roll Paper Margin Settings U “Setup menu” on
page 107
indicates factory default settings.
Roll Paper Margin
Parameter
Margin Values
Normal
A, C = 15 mm
*
B, D = 3 mm
Top15mm/Bottom15mm A, C = 15 mm
B, D = 3 mm
Top35mm/Bottom15mm A = 35 mm
C = 15 mm
B, D = 3 mm
Top45mm/Bottom15mm A = 45 mm
C = 15 mm
B, D = 3 mm
3mm A, B, C, D = 3 mm
15mm A, B, C, D = 15 mm
*
When Normal is selected, the value for A is 20 mm
for the following paper.
Premium Glossy Photo Paper (250)/Premium
Semigloss Photo Paper (250)/Premium Luster
Photo Paper (260)/Premium Semimatte Photo
Paper (260)
When the following media are used in CAD / Line
Drawing mode, the value for A and C is 3 mm.
Singleweight Matte Paper
c
Important:
❏ Printing is distorted when the trailing edge of
the roll paper comes off the core. Make sure the
trailing edge does not come inside the printing
area.
❏ The print size does not change even when the
margins are changed.
Cut Sheets Printable Area
When printing borderless on the left and right, the left
and right margins are 0 mm. (Borderless printing is not
available with poster board.)
SC-T7000 Series/SC-T5000 Series/SC-T3000 Series User's Guide
Basic Operations
51

Epson SureColor SC-T3000 Specifications

General

Color	Yes
Printing colors	Cyan, Magenta, Matte black, Photo black, Yellow
Print technology	Inkjet
Maximum resolution	2880 x 1440 DPI
Page description languages	HP-GL/2, HP-RTL
Package depth	1125 mm
Package width	787 mm
Package height	825 mm
Package weight	60910 g
Media thickness	0.08 - 1.5 mm
Maximum print size	A1 (594 x 841 mm)
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A1, A2, A3, A4
ISO B-series sizes (B0...B9)	B2, B3, B4
Display	LCD
Country of origin	Japan
Maximum internal memory	256 MB
Sound pressure level (printing)	50 dB
Number of power supply units	1
Power consumption (standby)	0.4 W
Power consumption (typical)	54 W
Power consumption (PowerSave)	3 W
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Quantity per pack	1 pc(s)
