Epson SureColor SC-T3000 User Manual

Cleaning the Printer
To keep your printer in optimum operating condition,
clean it (about once a month).
Cleaning the outside
A
Remove any paper from the printer.
B
Make sure the printer is turned off and the screen
has turned off, and then unplug the power cable
from the electrical outlet.
C
Use a soft, clean cloth to carefully remove any
dust or dirt.
If there is a serious dirt problem, clean it using a
soft, clean cloth dampened with a mild detergent.
Then wipe off with a dry, soft cloth.
c
Important:
Never use benzene, thinners, or alcohol to
clean the printer. They could cause
discoloration and deformities.
Cleaning the inside
Clean the pressure rollers if prints are smudged or
soiled.
Ink and particles of paper adhering to the platen should
be removed, as they may otherwise soil the paper.
c
Important:
Failure to remove dust and particles of paper from
the platen could result in clogged nozzles or damage
to the print head.
Cleaning the roller
Follow the steps below to clean the roller by feeding
plain paper.
A
Turn on the printer, and load it with widest
available roll paper.
U “Loading and Removing the Roll Paper” on
page 24
B
Press the ) button followed by the d button.
Paper is fed while the d button is pressed. If the
paper is not soiled, cleaning is complete.
Cut the paper after cleaning is done.
U “Manual cut method” on page 27
Cleaning inside
A
Make sure the printer is turned off and the screen
has turned off, and then unplug the power cable
from the electrical outlet.
B
Leave the printer for a minute.
C
Open the printer cover and use a soft, clean cloth
to carefully clean away any dust or dirt inside the
printer.
Thoroughly clean area (a), shown in blue in the
illustration below. To avoid spreading the dirt,
wipe from the inside to the outside. If there is a
serious dirt problem, clean it using a soft, clean
cloth dampened with a mild detergent. Then,
wipe the inside of the printer with a dry, soft
cloth.
SC-T7000 Series/SC-T5000 Series/SC-T3000 Series User's Guide
Maintenance
123

Epson SureColor SC-T3000 Specifications

General

Color	Yes
Printing colors	Cyan, Magenta, Matte black, Photo black, Yellow
Print technology	Inkjet
Maximum resolution	2880 x 1440 DPI
Page description languages	HP-GL/2, HP-RTL
Package depth	1125 mm
Package width	787 mm
Package height	825 mm
Package weight	60910 g
Media thickness	0.08 - 1.5 mm
Maximum print size	A1 (594 x 841 mm)
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A1, A2, A3, A4
ISO B-series sizes (B0...B9)	B2, B3, B4
Display	LCD
Country of origin	Japan
Maximum internal memory	256 MB
Sound pressure level (printing)	50 dB
Number of power supply units	1
Power consumption (standby)	0.4 W
Power consumption (typical)	54 W
Power consumption (PowerSave)	3 W
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Quantity per pack	1 pc(s)
