Epson TM-L90-i Technical Reference Guide

Chapter 3 Application Development Information
105
3
EPSON TMNet WebConfig
EPSON TMNet WebConfig is a Utility to set the printer on a web browser.
This section describes EPSON TMNet WebConfig using Internet Explorer as a browser.
Starting EPSON TMNet WebConfig
Follow the steps below to start up EPSON TMNet WebConfig.
1
Start up a PC connected to the network.
2
Start up the web browser and input the printer’s IP address 
(http://printer’s IP address) in the address bar as shown below.
http://xxx.xxx.xxx.xxx/PrinterConfigurationPage/
EPSON TMNet WebCon fig starts.
You can use API to check and make settings for this product from a user application. For
details, see TM-i Series WebConfig API User’s Manual.
 For the printer’s IP address, see the status sheet. For the status sheet, see "Confirming
with a status sheet" on page 78
.
 A user name and a password will be required on the authentication screen. Enter
“epson” for both the user name and the password. You can change the password on the
[Password Setting] screen (see
"Password Setting" on page 124.).

Epson TM-L90-i Specifications

General

Type	POS printer
Character size	0.99 x 2.4 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	180000 h
Product color	Gray
Maximum roll diameter	90 mm
USB port	Yes
USB connector	Micro-USB Type-A, Micro-USB Type-B, USB Type-A
USB 2.0 ports quantity	4
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Package depth	300 mm
Package width	190 mm
Package height	240 mm
Package weight	3000 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
