Epson TM-L90-i Technical Reference Guide

Chapter 1 Product Overview
15
1
Product Overview
This chapter describes features and specifications of the product.
Features
The TM-L90-i is a supporting ePOS-Print XML, high-speed, power-saving thermal receipt
printer that can print on die-cut/full-surface labels and thick paper. Its compact size allows
installation in a variety of areas. It is a model of the TM-i series.
Printing
•Printing on die-cut labels (labels pre-cut to the desired size) is possible.
•Printing on full-surface labels (labels cut to the desired size with an auto cutter) is possible.
•Printing on thick paper (up to 145µm) is possible.
•Supports a maximum paper width of 80mm, and paper widths of 38mm to 70mm when using
a roll paper spacer.
• Roll paper wit
h a maximum 90mm diameter can be used.
Handling
•Can be installed horizontally or vertically.
•Easy drop-in paper loading
•Cable connectors can be stored inside the printer.
Intelligent functions
•Supports ePOS-Print.
•Direct server printing with data sent from a web server to the printer (supported by ePOS-
Print XML)
•Printer driver is not required.

Epson TM-L90-i Specifications

General

Type	POS printer
Character size	0.99 x 2.4 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	180000 h
Product color	Gray
Maximum roll diameter	90 mm
USB port	Yes
USB connector	Micro-USB Type-A, Micro-USB Type-B, USB Type-A
USB 2.0 ports quantity	4
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Package depth	300 mm
Package width	190 mm
Package height	240 mm
Package weight	3000 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
