Epson TM-L90-i Technical Reference Guide

60
Adjustment procedure
1
Open the roll paper cover.
2
Use a coin or similar object to loosen the adjustment screw on the
detector.
3
Push the detection lever all the way to the rear window, and then turn
the knob until the detection lever is set in the position shown in the figure
below.
Changing from horizontal to vertical : Turn the knob towards you.
Changing from vertical to horizontal : Turn the knob away from you.
Horizontal position
Verti cal posit ion
Adjustment
screw
Knob
Detection
lever
Adjustment
screw
Knob
Detection
lever

Epson TM-L90-i Specifications

General

Type	POS printer
Character size	0.99 x 2.4 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	180000 h
Product color	Gray
Maximum roll diameter	90 mm
USB port	Yes
USB connector	Micro-USB Type-A, Micro-USB Type-B, USB Type-A
USB 2.0 ports quantity	4
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Package depth	300 mm
Package width	190 mm
Package height	240 mm
Package weight	3000 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
