Epson TM-L90-i Technical Reference Guide

72
Network Setting
There are two methods for network settings.
•EPSON TMNet WebConfig: Set from the computer's web browser
•EpsonNet Config: Set from EpsonNet Config, which is first installed on the computer.
The initial value for the IP address is the value acquired via DHCP. If automated acquisition of
an IP address via DHCP fails, set "192.168.192.168" as the IP address. When
the printer is turned
on, the IP address is acquired automatically and then printed. The setting method using EPSON
TMNet WebConfig is explained here. For more information about how to use EpsonNet Config,
refer to the EpsonNet Config Operations Guide.
Wired LAN Setting
Follow the steps below to set for wired LAN by using EPSON TMNet WebConfig.
 For more information about how to use EPSON TMNet WebConfig, see "EPSON TMNet
WebConfig" on page 105
.
 With either connection, wired LAN or wireless LAN, network setting for both the wired
LAN and wireless LAN is possible.
5
6
7
8

Epson TM-L90-i Specifications

General

Type	POS printer
Character size	0.99 x 2.4 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	180000 h
Product color	Gray
Maximum roll diameter	90 mm
USB port	Yes
USB connector	Micro-USB Type-A, Micro-USB Type-B, USB Type-A
USB 2.0 ports quantity	4
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Package depth	300 mm
Package width	190 mm
Package height	240 mm
Package weight	3000 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
