Epson TM-L90-i Technical Reference Guide

20
LEDs
Paper roll end(PAPER OUT) LED
•Lights when there is no more roll paper or there is little remaining.
•Off when there is a sufficient amount of roll paper remaining.
•Flashes when a self-test printing standby state and macro execution standby state.
Error(ERROR) LED
•Lights when the end of the roll paper is detected, and when printing has stopped (offline). If
this happens, replace the roll paper.
•Goes out during regular operation (online).
•Flashes when an error occurs. (For details about the flash codes, see "Error Status" on page 24.)
Power(POWER) LED (green)
•Lights when the power supply is on.
•Goes out when the power supply is turned off.
FEED button
When this button is pressed for receipt paper, the receipt is fed only 1line; for label paper, the
entire sheet is fed.
Holding this button down feeds the roll paper continuously.
You can use the memory switch (Msw8-3) to set whether the PAPER LED flashes when
there is little roll paper remaining.
(See
"Setting the Memory Switches" on page 96)

Epson TM-L90-i Specifications

General

Type	POS printer
Character size	0.99 x 2.4 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	180000 h
Product color	Gray
Maximum roll diameter	90 mm
USB port	Yes
USB connector	Micro-USB Type-A, Micro-USB Type-B, USB Type-A
USB 2.0 ports quantity	4
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Package depth	300 mm
Package width	190 mm
Package height	240 mm
Package weight	3000 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
