Epson TM-L90-i Technical Reference Guide

Chapter 1 Product Overview
39
1
Die-cut Label
Requirements for the thickness of the die-cut label paper, peeling strength against backing paper,
and the adhesive agent that can be used with the printer are shown in the figure below:
1) Paper Thickness, peeling strength, and adhesive agent
2) Requirements for transparency rate of die-cut label paper
Thermal paper (label)
Thickness: 70 to 92μm
Adhesive agent (acrylic emulsion)
Thickness: 9 to 21μm
Adhesive agent (acrylic emulsion)
Thickness: 41 to 71μm
Label + Backing paper:
Transparency rate: 18% or less
Backing paper:
Transparency rate: 47% or more

Epson TM-L90-i Specifications

General

Type	POS printer
Character size	0.99 x 2.4 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	180000 h
Product color	Gray
Maximum roll diameter	90 mm
USB port	Yes
USB connector	Micro-USB Type-A, Micro-USB Type-B, USB Type-A
USB 2.0 ports quantity	4
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Package depth	300 mm
Package width	190 mm
Package height	240 mm
Package weight	3000 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
