Epson TM-T70II-DT

36
Product Specifications
•High model (Page 36)
• Low model (Page 38)
High model
Item Specifications
CPU Usable CPU Intel

Atom
TM
Processor N2800 (1MB Cache, 1.86 GHz)
Memory Main memory 4 GB, DDR3-1066, SO-DIMM slot
BIOS SPI Flash 4MB
Chipset Intel

NM10
Video controller On built-in CPU
Auxiliary storage SATA SSD (16GB)
Interface Ethernet 10BASE-T/100BASE-TX/1000BASE-T 1port (RJ-45)
Support Wake On LAN Network boot
USB External: USB 2.0 x 6 (supports high/full/low speed)
Internal: USB 2.0 X 1 (for connecting to the printer)
Serial External x1 (9-pin DSUB male)
VGA External x1 (15-pin DSUB female)
DisplayPort External x 1 (standard DisplayPort connector 20-pin female)
Drawer External x1 (RJ12 6pin)
Line output
(Sound 
capability)
Outputs sound from internal speaker
External x1 (line output)
RTC/CMOS backup battery RTC is backed up by lithium primary battery
Speaker Internal monaural speaker
Product’s printer Thermal receipt printer at 250 mm/s on 80-mm wide roll paper
Software BIOS AMI BIOS (Supports ACPI 2.0/APM 1.2/Plug&Play)
OS Windows

Embedded POSReady 7
Device control
software
ePOS-Device
USB port controller (thin-client connection supported)
Power specifications
(Dedicated AC adapter)
AC100V - AC240 V / 50 Hz - 60 Hz
Main unit power consumption 13W (when not printing) / 47W (when printing)
