96
Communication Speed Switching
How to set the DIP switch
1
Disconnect the cable connecting the DM-D110.
2
Remove the DIP switch cover.
3
Switch the switch with something pointy.
4
Close the DIP switch cover.
Connecting the Customer Display
Connect the optional customer display (DM-D110) to this product with a USB cable.
When you want to use the product without any customer display, skip this section and go to the
next procedures.
SW1-5 SW1-6 SW1-7
Communication Speed
(bps)
ON ON ON 2400
OFF ON ON 4800
ON OFF ON 9600
OFF OFF ON 19200
ON ON OFF 38400
OFF ON OFF 57600
ON OFF OFF 115200
OFF OFF OFF (Reserved)
