Attaching the Optional Customer Display
Setting the Customer Display
DM-D110 has the DIP switches. The functions are follows.
•Displaying self-test
•Setting the communication speed (Serial communication)
In normal use, you do not need to change the settings. If you change this setting, match the
setting to that of the product. When used in ePOS-Device API / XML, you n
eed to set with
WebConfig.
DIP Switch Functions
*1
: Executes the self-test once only when the power is tuned on.
Remove the USB cable from the computer and remove the cover of the dip switch. If the
USB cable is still connected to the computer during operation, this product may break
down due to a short circuit, etc.
If you open the DIP switch cover, be sure to close the cover after setting the DIP switch.
When used without the cover, it may cause a malfunction.
DSW No. Function ON OFF Default
1-1 Received Error Data Ignore Displays "?" OFF
1-2 Receive Data Length 7bit 8bit OFF
1-3 Parity With Parity No Parity OFF
1-4 Parity Selection Even Odd OFF
1-5
Communication Speed
Switching
Refer to " Communication Speed
Switching"
ON
1-6 OFF
1-7 ON
1-8 Execution of Selt-Test *1 Yes No OFF
