Chapter 1 Product Overview
41
1
Printing Specifications
dpi: dots per inch
*1: When printing with the default print density level at 24V and 25°C {77°F}.
Printing method Thermal line printing
Cutting method Partial cut (cutting one point in left edge left uncut)
Dot density 180 × 180 dpi
Printing direction Unidirectional with friction feed (Reverse feed is not
supported.)
Printing width 72.2 mm (2.84"), 512 dots
Characters per line Font A (12 × 24) 42
Font B (9 × 17) 56
Maximum print speed*
1
250 mm/s
Line spacing 4.23 mm {1/5"} (Initial setting)
Character spacing 0.28 mm {0.0110”} (2 dots)
Printing speed may be slower, depending on the such items as the data transmission
speed.
