Epson TM-T70II-DT Technical Reference Guide

Chapter 2 Setup
63
2
Attaching the Optional Powered USB Hub Unit
Setting the Powered USB Hub Unit
The optional powered USB hub unit (OT-PH10) has a switch for changing settings. Change the
setting according to your usage.
Use tweezers to change the position of the switch.
Attaching the Powered USB Hub Unit
Follow the steps below to connect the powered USB hub unit to this product.
1
Connect the powered USB hub unit to TM-T70II-DT with the USB cables
provided with the powered USB hub unit.
Setting Description
1
Power is supplied/not supplied for the powered USB ports when the power of the
TM-T70II-DT is turned on/off, in accordance with the operation of the power
button of the TM-T70II-DT.
2
Power is always supplied for the powered USB ports regardless of the operation
of the power button of the TM-T70II-DT.

Epson TM-T70II-DT Specifications

General

Type	POS printer
Character size	0.99 x 2.4 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Product color	Black
Maximum roll diameter	83 mm
USB connector	USB Type-A
Serial interface	Yes
Standard interfaces	Ethernet, RS-232, USB 2.0, VGA
Serial interface type	RS-232
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Safety	TUV
RAM capacity	4 GB
Certification	CE, EN55022 Class A
Country of origin	China
Built-in processor	Atom N2800 1.86GHz
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Pallet width	800 mm
Pallet height	2005 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	112 pc(s)
Quantity per pallet layer	12 pc(s)
Quantity per pallet layer (UK)	16 pc(s)
Package depth	275 mm
Package width	237 mm
Package height	265 mm
Package weight	4420 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	290 mm
Width	172 mm
Height	114 mm
