38
Low model
Item Specifications
CPU Usable CPU Intel
Atom
TM
Processor N2600 (1MB Cache, 1.6 GHz)
Memory Main memory 2 GB, DDR3-800, SO-DIMM slot
BIOS SPI Flash 4Mbyte
Chipset Intel
NM10
Video controller On built-in CPU
Auxiliary storage SATA SSD (16GB)
Interface Ethernet 10BASE-T/100BASE-TX/1000BASE-T 1port (RJ-45)
Support Wake On LAN Network boot
USB External: USB 2.0 x 6 (supports high/full/low speed)
Internal: USB 2.0 X 1 (for connecting to the printer)
Serial External x1 (9-pin DSUB male)
VGA External x1 (15-pin DSUB female)
DisplayPort None
Drawer External x1 (RJ12 6pin)
Line output
(Sound
capability)
Outputs sound from internal speaker
External x1 (line output)
RTC/CMOS backup battery RTC is backed up by lithium primary battery
Speaker Internal monaural speaker
Product’s printer Thermal receipt printer at 250 mm/s on 80-mm wide roll paper
Software BIOS AMI BIOS (Supports ACPI 2.0/APM 1.2/Plug&Play)
OS Windows
Embedded POSReady 2009
Device control
software
ePOS-Device
Software required for connecting to Thin-Client
Power specifications
(Dedicated AC adapter)
AC100V - AC240 V / 50 Hz - 60 Hz
Main unit power consumption 12.2W (when not printing) / Nominal value 54W (when
printing)
External dimensions 172 mm {6.77”}(W) x 290 mm {11.42”}(D) x 114 mm {4.49”}(H)
(inclusive of cable cover)
Case color White / Black
Weight (Mass)
(roll paper excluded)
2.8 kg {6.17 lb}
