Appendix
Electrical Characteristics
AC adapter PS-180 Input voltage AC 90 V to 264 V (AC 100 V to 240 V)
Output voltage DC 24 V
Supply current from
the product
USB Total of both ports: 800 mA
Consumed current (Rating) 24 V /1.8 A
Consumed power When operating: 29.4W (230V/50Hz), 29.5W (115V/60Hz)
When standby: 2.9W (230V/50Hz), 2.8W (115V/60Hz)
Power supply On/Off Use the power switch on the product
If printing is continuously performed with a high ratio, the overcurrent protection may be acti-
vated and result in uneven print density or a low voltage error. Therefore, the printing length
must not exceed the following values when printing with high print ratio.
Print ratio: Number of dots being energized per one dot line/Total number of dots per one dot
line (512 dots)
Print ratio 80% 100%
Print example
Print length 30 mm 20 mm
58 mm
72 mm
