42
Connecting the AC Adapter
Use PS-180 as the power supply unit for this product.
Make sure that the power is turned off, and connect the AC adapter in the following steps.
1
Push the DC connectors of the AC adapter all the way into the DC-In
connectors of the product.
2
Push the connector of the power code all the way into the AC inlet of the
AC adapter.
3
Push the power plug all the way into the grounded outlet.
4
Place the AC adapter with the label facing down.
WARNING
• Be sure to use the included AC adapter as the power supply unit.
Using a nonstandard power supply can result in electric shock and fire.
• Should a fault ever occur in the included AC adapter, immediately turn off the power to
the product and unplug the power supply cable from the wall socket.
• Be sure to unplug the power supply unit’s cable from the wall socket whenever
connecting or disconnecting the power supply unit to the product.
Failure to do so may result in damage to the power supply unit or the product.
• Make sure the wall socket power supply satisfies the rated voltage requirements of the
power supply unit. Never insert the power supply cable plug into a socket that does
not meet the rated voltage requirements of the power supply unit.
Doing so may result in damage to both the power supply and the product.
DC-in connector
