ERROR list V 4.X
ERBOTOM ICC 350 (V4.0, V2.0), ICC 300 (V3.0),
ICC 200 (V2.0)
Automatic error detection, indication and documentation
ERBOTOM ICC series high-frequency surgical units are equipped with a device for automatic error detection,
indication and documentation (ERROR monitor).
Error detection, indication, documentation
For ERBOTOM ICC series equipment as of software version 2.0 / 4.0, the ERROR monitor can, depending
on the type of equipment and its outfit, detect up to 91 currently occurring errors (ERROR) and indicate them
on the display.
Error numbers (ERROR nos.) are assigned to the various errors. If an error is detected, it is immediately
reported. The error report is both visual and audible.
The error numbers of detected errors are automatically stored chronologically. Since only 10 memory locations
are available, only the last 10 error messages are displayed. If the same error is detected several times in a row,
the corresponding error number is then saved only once in consideration of the limited number of available
memory locations. The error numbers documented in memory can be displayed via Test program 2 and
deleted.
Troubleshooting for ICC family equipment
The ICC unit family is equipped with an error detection system which detects and stores the last 10 errors
detected in an ERROR list. This error memory can be called up via Test program no. 2. The user should thus
be capable of localizing errors himself and deciding whether this is an operating error or an error in the
accessories, which he can possibly eliminate himself, or whether it is necessary to make use of the technical
service.
If there is a complete failure of the system and no display is visible, the power supply may have been
interrupted or the voltage supply inside the unit is defective. In such a case, first check whether the outlet
used is live or a fuse in the house power supply has been tripped (Does a different unit function at this
outlet?). If the outlet used is live, check the powerline to the unit and replace if necessary. The equipment
fuses on the rear panel should also be checked and replaced if necessary.
ATTENTION!
Only use original fuses of the same specification.
If these efforts bring no results, there is probably an error within the unit. You should then contact the
technical service.
For a malfunction with a properly functioning display but with no indication of an ERROR number in the
display, the error may be located in defective accessories. It is possible, for example, that there may be a
defect in the fingerswitch or footswitch, or a disruption in the associated connecting cable. The cause of the
error may be determined by exchanging the accessories used.
To determine other causes of errors, an ERROR number in the unit display indicates the course of further
action according to the following table.
