1 TEST PROGRAMS AND ADJUSTMENTS40 / 266
Test program no. 11
Measurement value output for the
measurement channels
Using this program, you can measure the internal supply voltages and the temperature of the unit. In addition,
you can display all analog direct measurement channels 1, 2, 3 and 4 as well as analog multiplex measurement
channels.
After starting the test program, you will see the following display:
Display ICC 350 / 300
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
U0 XX.X
U– 1 XX.X
U2 XX.X
tPt ttt xxx
Ch 4 … 22 yyy
• XX.X Voltage value [V]
• ttt Temperature [°C]
• xxx ADC measurement value in the range 0 … 255
• yyy ADC measurement value in the range 0 … 255
Using the keys “Up” (8) or “Down” (9), call up the subprograms U, U-, tPt and Ch 4 … 22.
U0 is the low voltage controlled to +15 volts ±10%
U–1 is the low voltage controlled to –15 volts ±10%
U2 is the low voltage controlled to 24 volts ±10%
tPt is the temperature display of the output stage ±15%
Ch4 … 22 are the analog measurement channels according to the following table:
Display ICC 200
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
U.15 XX.X
–15 XX.X
U.24 XX.X
tPt ttt
C.aa yyy
To Next Page
