1 TEST PROGRAMS AND ADJUSTMENTS34 / 266
Display program no. 10:
Measurement values for activation of the sine-wave generator.
AUTO CUT, AUTO COAG 1 and 2 in SOFT mode, AUTO BIPOLAR
Output measurement value U
act
Display for the ICC 200:
AUTO CUT AUTO COAG
uuu U
uuu HF output voltage [V]
U Abbreviation of the test title (Voltage measurement)
Display program no. 11:
Measurement values for activation of the sine-wave generator.
AUTO CUT, AUTO COAG 1 and 2 in SOFT mode, AUTO BIPOLAR
Output measurement value cos j
Display for the ICC 200:
AUTO CUT AUTO COAG
cos Cos
cos cos-j value from the table
Cos Abbreviation of the test title (cos-j measurement)
Display programs nos. 10–11
