1TEST PROGRAMS AND ADJUSTMENTS33 / 266
Art. No.: 80116-201 09 / 2004
Display program no. 9:
Measurement values for activation of the sine-wave generator.
AUTO CUT, AUTO COAG 1 and 2 in SOFT mode, AUTO BIPOLAR
Output measurement values I
real
, cos j (Real part of the current and cos j between voltage and current)
Display for ICC 350 and ICC 300:
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
iii cos ppp IC
iii Real part of the measurement value from the HF output current
cos cos-j value from the table (ICC 350 only)
ppp HF power output [W] for ICC 350
IC Abbreviation of the test title (Current measurement and cos j measurement)
Display program no. 9:
Measurement values for activation of the sine-wave generator.
AUTO CUT, AUTO COAG 1 and 2 in SOFT mode, AUTO BIPOLAR
Output measurement value: Measurement value of the real part of the HF output current
Display for the ICC 200:
AUTO CUT AUTO COAG
iii I
iii Measurement value of the real part of the HF output current
I Abbreviation of the test title (Current measurement)
Display program no. 9
