1 TEST PROGRAMS AND ADJUSTMENTS46 / 266
Test program no. 16
Pre-information:
Jumper on the display board
General information
On the display board, there are slots for jumper which, by plugging in so-called “jumpers”, can activate
special software by which our HF surgical units from the ICC series can be adapted to prescribed special
conditions (such as are necessary in various countries) or by means of which specific tests can be performed
by the testing department and service.
WARNING
These jumpers are already positioned during production and must never be changed randomly. For a software
update, make certain that the jumpers are correctly plugged in. Back-up plugs are in the bag with the spare
fuses.
Where are the slots for the jumpers?
If you look at the display board inside the open unit from the perspective of the rear panel, the following
stylized image can be seen:
Two blocks are available to receive jumpers: At the top right is a block with the slots J3–J6, at the bottom
left (ICC 300: bottom right) is the block with the slots J7–J10.
3
6
J3–J6
710
J7–J10
Connector
to the CPU
LED display
LED display LED display LED display
710
J7–J10
Only at right on
ICC 300
