1TEST PROGRAMS AND ADJUSTMENTS47 / 266
Art. No.: 80116-201
09 / 2004
Block 1
Pos. Function Jumper plugged in Jumper
not
plugged in
J3
Only ICC 350:
Switchover of neutral
electrode to "capacitance
grounded" or "floating output".
Output circuitry with
capacitance ground.
Output circuitry is "floating
output".
J4
Only for test purposes.
Temperature display.
Maximum temperature of
generator is displayed
(ERROR 11).
The unit is delivered with this
setting.
J5 J5 functions together with J6. (see following explanation) (see following explanation)
J6 J6 functions together with J5. (see following explanation) (see following explanation)
The J5 and J6 slots are read by the CPU as a binary number. In this way four different functioning methods,
independent from one another, are programmable by plugging in these jumpers:
J5 J6 Description of the set function
free free None of the following 3 programs is selected.
plugged free Contact monitor is blocked and AUTO START display is "off".
free plugged
During activation, another activation signal from some other source has switched off
the unit activation (Spanish regulation).
plugged plugged
F leakage current > 150 mA, but < 300 mA:
Triple visual and acoustic alarm is triggered.
HF leakage current > 300 mA:
The HF generator is switched off. Visual and acoustic alarm is triggered.
Test program no. 16
Pre-information:
Jumper on the display board
