Block 2 (as of Version 1.06)
Pos. Function Jumper plugged in Jumper
not
plugged in
J7 (not in use) (not applicable) (not applicable)
J8
Low-resistance load operation
< 5 ohms triggers ERROR 30
to protect accessories and
generator.
ERROR 30 can be
deactivated here when
activating AUTO BIPOLAR.
Deactivation of ERROR 30
possible for BIPOLAR COAG
(as of V 2.00):
- after 4 s red LED (output
error)
- Output current max. 1.5 A
- no ERROR indication
(This specification especially
applies to the USA.)
ERROR 30 warning appears
due to delivery status
(not USA, ERROR 30
deactivated here).
Regardless of the selection, special settings are necessary for specific countries. These can be found in the
following matrix. Explanation:
1 Jumper must be plugged in,
o Jumper must not be plugged in,
x (according to the description for Block 1).
Country J5 J6 J7 J8
Germany o o no function per above table
European countries
(excepted:
see below)
o o no function per above table
Great Britain 1 o no function per above table
Spain o 1 no function per above table
Japan 1 1 no function per above table
USA x x no function 1
Test program no. 16
Pre-information:
Jumper on the display board
