1 TEST PROGRAMS AND ADJUSTMENTS30 / 266
Display program no. 4:
ST generator measurement values with ST generator activation.
Output measurement values U
st
, I
st
Display for ICC 350 and ICC 300:
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
uuu iii P 3 UI
uuu Measurement value of the output voltage sensor
iii Measurement value of the output current sensor
P 3 Set power [W]
UI Abbreviation of the test title (Voltage and current measurement)
Display program no. 4:
ST generator measurement values with ST generator activation.
FORCED activation
Display for ICC 200:
AUTO CUT AUTO COAG
uuu USt
uuu Measurement value of the output voltage sensor
Display program no. 5:
Power supply unit measurement values for ST generator activation.
Measurement values U
nt
, I
nt
Display for ICC 350 and ICC 300:
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
uuu iii P 3 UI
uuu Measurement value of the power supply unit voltage
iii Measurement value of the power supply unit current
P3 Set power
UI Abbreviation of the test title (Voltage, current measurement)
Display programs nos. 4–5
